Ventis 200 T Sprayer

Applications

Canopy vineyard and kiwi plants

Category

Trailed

Type of spraying

Pneumatic sprayer

Pneumatic trailed sprayer

Pneumatic trailed sprayer of very compact size, specifically designed for small tractors. It can be operated also from 24 HP tractors. Equipped with an high efficiency centrifugal fan, it creates an air flow able to ensure an excellent micronization of droplets and the proper spraying penetration also in thick vegetation.
Available with a 200 liters tank, fully independent and adjustable Nobili outlets and a centrifugal brass pump (80 l/min).
This low volume sprayer is the perfect solution for precision spraying (hormones and ripening treatments), also in the most difficult situations when bigger machines would require too much power.

Technical features   451-200 T
Lt. capacity lt 200
Ø 450 D.A.
rpm 3780
m/sec 150
mc/h 3300
Power HP 20-30
KW 15-22
Measures A mm 2200
B mm 1090
C mm 1260
Weight KG 165
