TBE - TBE-S serie 102 Mulcher
Specialized professional mulcher for green spaces
Sturdy mulchers - with parallelogram arm - specialized for green spaces, embankments and roadsides. TBE and TBE-S series 102 mulchers are suitable for contractors because they are manufactured with components assuring a long life and a very few maintenance. The offset over the tractor’s roadways gives the possibility to work sideways even in tilted position for the cleaning of embankments or ditches and in vertical position for the cutting of hedges. The rotor is equipped with interchangeable knives. Working widths: 1900 - 2200 - 2400 - 2600 mm.
| Technical features | TBE 192 | TBE 222 | TBE 242 | TBE-S 192 | TBE-S 222 | TBE-S 242 | TBE-S 262 | |
|---|---|---|---|---|---|---|---|---|
| Connecting position | Rear | Rear | Rear | Rear | Rear | Rear | Rear | |
| Working width | mm | 1792 | 2144 | 2295 | 1792 | 2144 | 2295 | 2496 |
| Engine speed pdp | rpm | 540 | 540 | 540 | 540 | 540 | 540 | 540 |
| Tractor horse power | HP | 80-130 | 90-150 | 100-170 | 80-130 | 90-150 | 100-170 | 110-180 |
| KW | 59-96 | 66-110 | 74-125 | 59-96 | 66-110 | 74-125 | 81-132 | |
| Rotor speed | rpm | 2205 | 2205 | 2205 | 2205 | 2205 | 2205 | 2205 |
| Pruning residues | < | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm | < 5 cm |
| Blades | 01 | 40 | 48 | 52 | 40 | 48 | 52 | 56 |
| 06 | 20 | 24 | 26 | 20 | 24 | 26 | 28 | |
| Measures | A | 2060 | 2423 | 2572 | 2330 | 2694 | 2920 | 3121 |
| B | 1222 | 1222 | 1222 | 1222 | 1222 | 1222 | 1222 | |
| C | 768 | 768 | 768 | 768 | 768 | 768 | 768 | |
| Weight | KG | 925 | 980 | 1030 | 960 | 1015 | 1065 | 1100 |
